PriceList for High Pressure Braided Rubber Air Hose
Fast and great quotations, informed advisers to help you choose the correct solution that suits all your requirements, a short creation time, responsible top quality manage and distinct providers for paying and shipping affairs for PriceList for High Pressure Braided Rubber Air Hose, For top quality gas welding & cutting equipment supplied on time and at the right value, you can count on firm name.
Fast and great quotations, informed advisers to help you choose the correct solution that suits all your requirements, a short creation time, responsible top quality manage and distinct providers for paying and shipping affairs for China Rubber Air Hose and High Pressure Air Hose, We have now been in operation for more than 10 years. We are dedicated to quality products and consumer support. We currently own 27 product utility and design patents. We invite you to visit our company for a customized tour and advanced business guidance.
Rubber air hose/ tube,one of its uses is used as the connector between air compressor and other devices. It is widely used in underwater diving, diving dress and other types of surface supplied diving equipment. In the other hand, air hoses can also be used for air brakes between tractors and semi-trailers,used for conveying of air, inert gas and water in mining, construction, engineering, shipbuilding, steel production etc.
Rubber air hose is composed of three parts: tube, reinforcement and cover. The tube is made from high quality black and smooth synthetic rubber, mainly NBR, which is resistant to abrasion, corrosion and oils. The reinforcement is made from multiple layers of high strength synthetic fiber, making the hose have solid structure. The cover is made from high quality black and smooth synthetic rubber, is resistant to fire, abrasion, corrosion, oils, weather, ozone and aging. The hose has a long service life as a result..
Features
Tube: Synthetic rubber
Reinforcement: High tensile tire cord braid or spiral
Cover: weather resistant synthetic rubber
Temperature: -30°C to 150°C
Color: Black or customized
Characteristics: Oil resistant tube Anti-aging synthetic rubber Weather and ozone resistant Excellent abrasion resistance
Soft, lightweight and good bending performance
General Specifications
|
Inner diameter |
Outer diameter |
Working pressure |
Burst pressure |
Bend radius |
Weight |
Length |
|
|
inch |
mm |
mm |
MPa |
MPa |
mm |
kg/m |
m/roll |
|
1/4″ |
6 |
15.5 |
2 |
6 |
102 |
0.308 |
100 |
|
5/16″ |
8 |
17.5 |
2 |
6 |
114 |
0.324 |
100 |
|
3/8″ |
10 |
19.5 |
2 |
6 |
127 |
0.4 |
100 |
|
1/2″ |
13 |
23 |
2 |
6 |
178 |
0.548 |
100 |
|
5/8″ |
16 |
26 |
2 |
6 |
203 |
0.6 |
100 |
|
3/4″ |
19 |
30.5 |
2 |
6 |
241 |
0.76 |
100 |
|
1″ |
25 |
38 |
2 |
6 |
305 |
1.08 |
100 |
|
1-1/4″ |
32 |
46 |
2 |
6 |
419 |
1.28 |
50 |
|
1-1/2″ |
38 |
56 |
2 |
6 |
500 |
1.72 |
50 |
|
2″ |
51 |
70 |
2 |
6 |
630 |
2.9 |
50 |
Product Display
Fast and great quotations, informed advisers to help you choose the correct solution that suits all your requirements, a short creation time, responsible top quality manage and distinct providers for paying and shipping affairs for PriceList for High Pressure Braided Rubber Air Hose, For top quality gas welding & cutting equipment supplied on time and at the right value, you can count on firm name.
PriceList for China Rubber Air Hose and High Pressure Air Hose, We have now been in operation for more than 10 years. We are dedicated to quality products and consumer support. We currently own 27 product utility and design patents. We invite you to visit our company for a customized tour and advanced business guidance.
